PVC Insulated and Sheathed Conductor Control Cables 0.6/1kV

Multi-core cables with copper conductors, PVC insulated, armoured or unarmoured and PVC sheathed. Cables are rated 0.6/1 KV and conform to IEC:502.

CONTACT NOW PDF Download

Details

Tags

Product details

Construction

Conductor:Plain circular solid or stranded copper, per IEC:228, class 1 and 2 - sizes: 1.5 mm2, 2.5 mm2 and 4 mm2

Insulation: Heat resistive PVC type 5 to BS:6746 rated 85°C for continuous operation (PVC type 1 to BS:6746 rated 70°C also available)

Assembly & Filling

For armoured cables

Insulated cores are laid up together and filled with non-hygroscopic material to form compact and circular cable. Armour bedding shall be an extruded layer of PVC which may be an integral part of the filling.

For unarmoured cables

Insulated conductors are laid up together and provided with lapped or extruded inner covering.

Armour

Galvanized steel tapes or round steel wires.

Sheath

PVC type ST2 to IEC:502 colour black. Flame retardant PVC is also available upon request.

Core identification

Black with white printed numbers 1,2,3...etc.

Standard number of cores

7, 12, 19, 24, 30, 37. Different number of cores are available on request.

Application: These cables are suitable for use in a broad range of commercial, in industrial and utility applications where maximum performance will be demanded and may be installed indoors, outdoors, underground, ducts (conduits), on trays or ladders.
