BS CABLE

Kebo za msingi moja zilizo na kondakta dhabiti au zilizokwama, maboksi ya PVC, iliyokadiriwa 450/750V kulingana na SASO:55 vipimo.

Nyaya nyingi za msingi zilizo na makondakta wa shaba, maboksi ya PVC, ya kivita au yasiyo na silaha na kufunikwa kwa PVC. Kebo zimekadiriwa 0.6/1 KV na zinalingana na IEC:502.

Kebo za msingi moja na kondakta wa shaba, XLPE iliyowekewa maboksi, ala ya ndani ya halojeni isiyolipishwa, yenye kivita na iliyofunikwa kwa LSF-FR-HF. Kebo zimekadiriwa 0.6/1 KV na zinalingana na BS:6724 na BS:7211

WASILIANA NA SASA Upakuaji wa PDF

Maelezo

Lebo

Single Core,PVC Insulated Annealed Copper Conductors (450/750V)

Maelezo ya bidhaa optic fibre

Ujenzi

Kondakta

Plain annealed circular copper conforming to IEC:228, class 1 and 2 (also available in aluminum conductors sizes 16 to 630 mm2).

Uhamishaji joto

PVC type 5 to BS:6746 rated 85°C, (PVC type 1 to BS:6746 rated 70°C also available)

Application: Typical applications include building wiring, equipment wiring, switching and distribution installations in conduits above or under plaster

Features: Insulation adheres tightly to conductors yet strips easily, leaving conductor clean. PVC insulation has good electrical properties.

Vipimo NA UZITO starlink cable

Kondakta		Uhamishaji joto		Ufungaji
Cross sectional area Jina	Nambari ya chini of wires	Unene Nominella	Kipenyo cha jumla Takriban	Uzito wa jumla Takriban	B-Box, S-Spool C-Coil, D-Drum
m m2		m m	m m	kg/km	m
1.5 re	1	0.7	3.0	19	50/100 B/S
1.5 rm	7	0.7	3.2	19	50/100 B/S
2.5 re	1	0.8	3.6	30	50/100 B/S
2.5 rm	7	0.8	3.8	31	50/100 B/S
4 re	1	0.8	4.1	47	50/100 B/S
4 rm	7	0.8	4.3	48	50/100 B/S
6 re	1	0.8	4.6	66	50/100 B/S
6 rm	7	0.8	4.9	67	50/100 B/S
10 re	1	1.0	5.9	110	50/100 C
10 rm	7	1.0	6.3	113	50/100 C
16 rm	7	1.0	7.3	171	50/100 C
25 rm	7	1.2	9.0	268	50/100 C
35 rm	7	1.2	10.1	361	1000/2000 D
50 rm	19	1.4	12.0	483	1000/2000 D
70 rm	19	1.4	13.8	680	1000/2000 D
95 rm	19	1.6	16.0	941	1000/2000 D
120 rm	37	1.6	17.6	1164	1000 D
150 rm	37	1.8	19.7	1400	1000 D
185 rm	37	2.0	22.0	1800	1000 D
240 rm	61	2.2	25.0	2380	1000 D
300 rm	61	2.4	27.7	2970	500 D
400 rm	61	2.6	31.3	3790	500 D

re - circular solid conductor rm - circular stranded conductor

PVC Insulated and Sheathed Control Cables 0.6/1kV

Unarmoured Control Cables

Maelezo ya bidhaa dsl cable

Ujenzi

Conductor:Plain circular solid or stranded copper, per IEC:228, class 1 and 2 - sizes: 1.5 mm2, 2.5 mm2 and 4 mm2

Insulation: Heat resistive PVC type 5 to BS:6746 rated 85°C for continuous operation (PVC type 1 to BS:6746 rated 70°C also available)

Assembly & Filling

For armoured cables

Insulated cores are laid up together and filled with non-hygroscopic material to form compact and circular cable. Armour bedding shall be an extruded layer of PVC which may be an integral part of the filling.

For unarmoured cables

Insulated conductors are laid up together and provided with lapped or extruded inner covering.

Silaha

Kanda za chuma za mabati au waya za chuma za pande zote.

Ala

PVC type ST2 to IEC:502 colour black. Flame retardant PVC is also available upon request.

Core identification

Black with white printed numbers 1,2,3...etc.

Standard number of cores

7, 12, 19, 24, 30, 37. Different number of cores are available on request

Application: These cables are suitable for use in a broad range of commercial, in industrial and utility applications where maximum performance will be demanded and may be installed indoors, outdoors, underground, ducts (conduits), on trays or ladders.

Low Smoke Fums,Fire Retardant,Halogen Fire Cable - Copper Conductors 0.6/1kV

Maelezo ya bidhaa fastest ethernet cable

Kondakta wa Ujenzi

Plain circular or sector stranded copper conductors, per IEC:228 class 1 and 2.

Uhamishaji joto

XLPE (cross-linked polyethylene) rated 90°C.

Bunge

Two, three or four insulated cores are assembled together.

Inner sheath

In single core cables, inner sheath of halogen free compound is applied over insulation. In multicore cables, assembled cores are covered with

inner sheath of halogen free compound.

Silaha

For single core cables, a layer of aluminium wires applied helically over inner sheath. For multicore cables, galvanised round steel wires applied helically over inner sheath.

Ala

LSF-FR-HF compound, colour black.

Colours for core identification

Single core - red (black colour on request) Two cores - red and black

Three cores - red, yellow and blue

Four cores - red, yellow, blue and black

Features: Cables manufactured with the above construction have a combination of high flame retardancy as well as low smoke and non-halogen acid gas generation. This makes these cables ideal to install in locations such as chemical plants, hospitals, military installations, underground railways, tunnels, etc

Application: These cables are intended for installation on cable trays or in cable ducts.

Vipimo NA UZITO high speed ethernet cable

Awa armoured LSF-FR-HF Cables- Single Core Copper Conductor - XLPE Insulated 0.6/1kV

Kondakta		Uhamishaji joto	Kuweka silaha	Outer sheath		Ufungaji
Cross sectional area Nominal	Idadi ya chini ya waya	Unene Nominella	Diameter of aluminium wire Jina	Unene Nominella	Kipenyo cha jumla Takriban	Net uzito Appro x	Kifurushi cha kawaida
mm²	Idadi ya chini ya waya	mm	mm	mm	mm	kg/km	m±5%
50	6	1.0	1.25	1.5	18.2	710	1000
70	12	1.1	1.25	1.5	20.2	940	1000
95	15	1.1	1.25	1.6	22.3	1220	1000
120	18	1.2	1.25	1.6	24.2	1480	1000
150	18	1.4	1.60	1.7	27.4	1870	500
185	30	1.6	1.60	1.8	30.0	2280	500
240	34	1.7	1.60	1.8	32.8	2880	500
300	34	1.8	1.60	1.9	35.6	3520	500
400	53	2.0	2.00	2.0	40.4	4520	500
500	53	2.2	2.00	2.1	44.2	5640	500
630	53	2.4	2.00	2.2	48.8	7110	500

RSW Armoured LSF-FR-HF Cables - Multi Core Copper Conductors- XLPE Insulated 0.6/1kV

Kondakta		Uhamishaji joto	Kuweka silaha	Outer sheath		Ufungaji
Sehemu ya msalaba Nominella	Idadi ya chini ya waya	Unene Nominella	Kipenyo cha waya wa alumini Jina	Unene Nominella	Kipenyo cha jumla Takriban	Uzito wa jumla Takriban	Kifurushi cha kawaida
mm2	Idadi ya chini ya waya	mm	mm	mm	mm	kg/km	m±5%
2.5 rm	7	0.7	1.25	1.4	14.3	500	1000
4 rm	7	0.7	1.25	1.4	15.4	560	1000
6 rm	7	0.7	1.25	1.4	16.6	670	1000
10 rm	7	0.7	1.25	1.5	18.7	850	1000
16 rm	6	0.7	1.25	1.5	20.0	1060	1000
25 rm	6	0.9	1.25	1.6	24.1	1620	1000
35 rm	6	0.9	1.60	1.7	23.4	1930	500
2.5 rm	7	0.7	1.25	1.4	14.8	540	1000
4 rm	7	0.7	1.25	1.4	16.0	620	1000
6 rm	7	0.7	1.25	1.4	17.3	755	1000
10 rm	7	0.7	1.25	1.5	20.2	960	1000
16 rm	6	0.7	1.25	1.6	21.2	1240	1000

rm - circular stranded conductor sm - sectoral stranded conductor

Maelezo ya bidhaa optic fibre

Kebo ya Msingi Moja

1. Kondakta

2. Aina ya 5 ya insulation ya PVC

3. PVC

Multi-msingi Cable

1. Kondakta

2. Insulation ya PVC

3. Matandiko ya nje
4. Ala ya PVC

dsl cable

Multi-msingi Cable

1. Alumini ya Kisekta/Kondakta wa Shaba
2. Aina ya 5 ya insulation ya PVC
3. Filler ya Kati
4. Matandiko ya nje
5. Waya wa chuma wa pande zote wenye kivita
6. Ala ya kiwanja cha LSF-FR-HF

fastest ethernet cable

dsl cable

fastest ethernet cable

high speed ethernet cable

optic fibre

starlink cable

Ikiwa una nia ya bidhaa zetu, unaweza kuchagua kuacha maelezo yako hapa, na tutawasiliana nawe baada ya muda mfupi.

Andika ujumbe wako hapa na ututumie
