Type W Three-Conductor Portable Power Cable 2kV

These cables are designed for general use where bare grounding conductors are not required or desired .

Standards

CONTACT NOW PDF Download

Details

Standards

Construction

1. Stranded Tinned Copper Conductor

2. EPR Insulation

3. Reinforced CPE Jacket

Options

Other jacket materials/color such as CSP/PCP/NBR/PVC are available upon request.

Two-layer jacket with reinforcing fiber between the two layers can be offered as an option.

Mechanical and Thermal Properties

Dimensions and Weight

Construction	No. of Strands	Nominal Insulation Thickness		Nominal Overall Diameter		Nominal Weight		Ampacity
No. of cores×AWG/kcmil	-	inch	mm	inch	mm	lbs/kft	kg/km	A
3×8	133	0.06	1.5	0.91	23.1	550	818	59
3×6	133	0.06	1.5	1.01	25.7	730	1086	79
3×4	259	0.06	1.5	1.17	29.7	1020	1518	104
3×2	259	0.06	1.5	1.34	34.0	1430	2128	138
3×1	259	0.08	2.0	1.51	38.4	1800	2678	161
3×1/0	266	0.08	2.0	1.65	41.9	2140	3184	186
3×2/0	342	0.08	2.0	1.75	44.5	2580	3839	215
3×3/0	418	0.08	2.0	1.89	48.0	2922	4347	249
3×4/0	532	0.08	2.0	2.04	51.8	3800	5654	287
3×250	741	0.095	2.4	2.39	60.7	4368	6500	320
3×350	888	0.095	2.4	2.66	67.5	5895	8772	394
3×500	1221	0.095	2.4	2.98	75.8	7820	11638	487
