Welding Cable

Cable ya kulehemu

The tin-coated or bare copper conductor is sheathed with natural rubber or chloroprene rubber.A layer of Mylar film is applied between conductor and sheath for separating.

Application: This product is suitable for power supply to welding machine or similar equipment. Rated Voltage: 300/500V.





Upakuaji wa PDF

Maelezo

Lebo

Maelezo ya bidhaa



Joto la Uendeshaji: Max permissible continuous operating temperature of conductor shall not exceed 65oC.

Kawaida: 245IEC81,245IEC82,GB5013.6- 1997 or other standards required by customers.

Ufungashaji: Steel/wooden reel,,wooden reel or steel reel.



Maelezo ya bidhaa



1. Tin-coated or bare copper conductor

2. Mylar film tape separator

3. CPE rubber sheath


Type,Description and Application Range



Type

Maelezo

Masafa ya Maombi



YH

Copper conductor rubber sheathed welding cable

Suitable for connecting the secondary wire of welding machine at

AC earth voltage 200V and DC impulse peak 400V or connecting

the welding clamp.

YHF



Copper conductor chloroprene rubber sheathed welding cable

Suitable for connecting the secondary wire of welding machine at

AC earth voltage 200V and DC impulse peak 400V or connecting

the welding clamp.The cable is resistant to weather and

oil,suitable for outdoor condition or places where oil exists.



Sifa za Kiufundi



Cable ya kulehemu

Type YH, YHF

Nominal Area of Conductor

Stranding No/Dia

Separator Thickness

Unene wa Ala

Average

Kwa ujumla

Kipenyo

Max DC

Kondakta

upinzani

at 20C

Approx weight of

cable

(kg/km)

Hapana x mm2

No/mm

mm

mm

mm

Ω/km

YH

YHF

16

25

35

504/0.20 783/0.20 1107/0.20

0.7

0.7

0.7

1.3

1.3

1.3

10.1

11.6

12.6

1.16

0.758

0.536

217

310

411

227

322

424

50

70

95

1566/0.20 2146/0.20 2976/0.20

0.7

0.8

0.9

1.5

1.6

1.7

15.0

17.4

19.9

0.379

0.268

0.198

576

786

1047

592

808

1075
