Single Core,PVC Insulated Annealed Copper Conductors (450/750V)

Single core cables with solid or stranded copper conductors, PVC insulated, rated 450/750V conforming to SASO:55 specification.

CONTACT NOW PDF Download

Details

Tags

Product details

Construction: Plain annealed circular copper conforming to IEC:228, class 1 and 2 (also available in aluminum conductors sizes 16 to 630 mm2).

Insulation: PVC type 5 to BS:6746 rated 85°C, (PVC type 1 to BS:6746 rated 70°C also available)

Application: Typical applications include building wiring, equipment wiring, switching and distribution installations in conduits above or under plaster

Features: Insulation adheres tightly to conductors yet strips easily, leaving conductor clean. PVC insulation has good electrical properties.

Dimensions and Weights

Conductor		Insulation		Packaging
Cross sectional area Nominal	Minimum number of wires	Thickness Nominal	Overall diameter Approx	Net weight Approx	B-Box, S-Spool C-Coil, D-Drum
m m2		m m	m m	kg/km	m
1.5 re	1	0.7	3.0	19	50/100 B/S
1.5 rm	7	0.7	3.2	19	50/100 B/S
2.5 re	1	0.8	3.6	30	50/100 B/S
2.5 rm	7	0.8	3.8	31	50/100 B/S
4 re	1	0.8	4.1	47	50/100 B/S
4 rm	7	0.8	4.3	48	50/100 B/S
6 re	1	0.8	4.6	66	50/100 B/S
6 rm	7	0.8	4.9	67	50/100 B/S
10 re	1	1.0	5.9	110	50/100 C
10 rm	7	1.0	6.3	113	50/100 C
16 rm	7	1.0	7.3	171	50/100 C
25 rm	7	1.2	9.0	268	50/100 C
35 rm	7	1.2	10.1	361	1000/2000 D
50 rm	19	1.4	12.0	483	1000/2000 D
70 rm	19	1.4	13.8	680	1000/2000 D
95 rm	19	1.6	16.0	941	1000/2000 D
120 rm	37	1.6	17.6	1164	1000 D
150 rm	37	1.8	19.7	1400	1000 D
185 rm	37	2.0	22.0	1800	1000 D
240 rm	61	2.2	25.0	2380	1000 D
300 rm	61	2.4	27.7	2970	500 D
400 rm	61	2.6	31.3	3790	500 D
